PCBA Manufacturing

Performance Requirements for High-Tech PCBA Manufacturing Demand Expertise in Current and Evolving Technologies

From a simple product design to an advanced PCBA with hundreds of components and multiple layers, NEOTech’s PCBA manufacturing services provide our customers the outsourcing solutions to overcome challenges on the road to deliver industry-leading products.

Whether you refer to them as Printed Circuit Card Assemblies (PCBA) or Circuit Card Assemblies (CCA), NEOTech continues to excel at its core foundation of providing expert electronics manufacturing. With decades of experience in PCBA manufacturing for an almost endless array of diverse products, we employ a talented workforce of highly skilled and trained technicians all utilizing state-of-the-art manufacturing capital equipment.

Our PCBA manufacturing teams are always investigating the latest equipment to utilize on our SMT lines to ensure we offer a complete end-to-end solution. Plus, with our commitment to a culture of continuous improvements, our facility leadership meets regularly with the manufacturing teams to identify inefficiencies and then implement solutions. All this combined ensures shorter cycle-times, less production fall-out, and ultimately lower-costs for your products.

PCBA/CCA Manufacturing Overview:

  • Package sizes down to 01005 form factor
  • Micro-BGAs and part-on-part capabilities down to 0.5 mm pitch in production with 0.3 mm pitch process capability
  • Expert PCBA design services
  • Package-on-Package (PoP) capabilities
  • Expert circuit card assembly
  • Automated and semi-automated plated through-hole (PTH) assembly
  • Large form factor PCBAs
  • High density PCBAs
  • Column grid arrays and ceramic standoffs
  • IC programming
  • Highly flexible wave solder systems with selective solder capabilities
  • Options for clean zone assembly areas with FOD and ESD controls
  • Automatic product transfer system and adhesive/solder paste dispense with 3D inspection
  • Automatic vision-guided stencil print
  • Upfront process characterization
  • Automatic precision component placement @ 420K per hour per line
  • Linear aqueous or semi-aqueous cleaner
  • Flex and rigid flex manufacturing on various finishes such as bare copper, OSP, ENiAg, and ENiAu
  • Alternative laminate substrates such as aluminum and copper core for thermal applications
  • High dielectric and controlled impedance > 20 layers
  • Conformal coating capabilities for silicon base, acrylic, and urethane
  • Oblique x-ray inspection for Failure Analysis
  • Automatic boat transfer system – Surface Mount Equipment Manufacturers Association (SMEMA) compliant
  • PCBA services include availability of low cost regions with redundant equipment in the U.S.

High-Tech Industry-Leading Equipment for the Highest-Quality PCBA Manufacturing

Screen Printers

  • Allow quick product changeover
  • Solder parameters driven by each order’s bar code, eliminating setups
  • Six sigma production performance

Solder Paste Inspection

  • 3D inspection
  • Interfaces with screen printers to automatically adjust settings on the screen printer

SMT Placement Machines

  • >35K placements per hour per placement head
  • Allow quick product changeover
  • Enhanced digital imaging
  • Latest technology Flux Dip application

Optical Inspection

  • AOI and manual systems
  • Ensures high levels of product quality
  • Automated means of detecting part presence/absence, polarity, and solder defects
  • Vector-based algorithms
  • Rapid cycle time

X-Ray Inspection

  • AXI and manual systems
  • Digital cross-sectional x-ray images of solder joints
  • Enables inspection of both sides of a double-sided panel
  • Inline or offline options

Your product is vital and must meet your customer's quality demands

Expand your team to include NEOTech’s industry experts. Contact us and let’s discuss your specific design and product requirements, and together – we’ll find a solution tailored to fit your needs.
